Cross Shaft 12mm Micro Planetary Gear Motor 3V 5V 9V Rare Earth Medium Strength Magneto N20 Single Stage Planetary Gear Motor

Cross Shaft 12mm Micro Planetary Gear Motor 3V 5V 9V Rare Earth Medium Strength Magneto N20 Single Stage Planetary Gear Motor

Specifications:

Diameter 12mm micro planetary reducer motor, high quality N20 rare earth medium intensity magneto, reducer box is a single-stage planetary gear reduction, deceleration output shaft is a cross shaft.

Speed motor rated DC 9V, measured voltage 3-9V can run, even if the step-down to 3V, the output shaft can not be blocked by hand, the strength is still good, the actual use depends on their own needs to test.

The measured output speed of the gear motor under different voltages is as follows:

Voltage 3V: no-load current 18mA, no-load speed 56 RPM.

Voltage 5V: no load current 20mA, no load speed 100 RPM.

Voltage 9V: no-load current 30mA, no-load speed 180 RPM.

The gear motor weighs about 6.7 grams.

Note:

1.Due to the light and screen difference, the item's color may be slightly different from the pictures.

2.Please allow 1-3cm differences due to manual measurement.

Package Includes:

1x Planetary Gear Motor
