5EPJ1163 Washer Belt 5PJE1163 Drive Belt Fit Brandt 52X5974 Compatible with Bosch 00745310 Fagor

Product Overview
This 5EPJ1163 Poly-V Drive Belt is a 5-rib elastic belt for selected Brandt, Fagor, Bosch and Siemens front-load washers. It transfers power from the motor to the drum.

A worn or broken belt can cause the drum not to turn, slipping noise, or incomplete spin.

Key Features

• Part Number: 5EPJ1163
• Universal / Alternative Numbers: 5PJE1163 1163J5EL 1163PJ5E 52X5974 00672911 00745310 00351834 55X2987
• Type: Elastic Poly-V / Multi-Rib Washer Drive Belt
• Specification: 5 ribs · J profile · Length 1163 mm · EPJ / PJE / EL elastic
• Material: High-quality rubber with reinforced cords
• Quantity: 1 piece

Installation Instructions

1. Unplug the washer and disconnect power.
2. Remove the back panel to access the motor and drum pulley.
3. Confirm the old belt is marked 5EPJ1163 / 5PJE1163 / 52X5974.
4. Take off the old belt.
5. Stretch the new elastic belt onto the drum pulley first, then onto the motor pulley.
6. Make sure all 5 ribs sit in the grooves.
7. Reassemble, restore power, and run a short test cycle.

Compatibility / Fit Models
This 5-rib 1163 mm belt fits selected washers that list this stamp.

Brandt / Fagor / Vedette / Thomson
BWT1512E BWT1612E BWT1613T BWT2512E BWT2612E BWT3612E BWT3613T BWT630F
BWF171T BWF174T BWF184T BWF194Y
WFA1047E WFA1247E WFA1217F
WTG691000 WT4026 LP-2086

Bosch / Siemens / Balay
WAB20262BY Selected WOR WOT WP series that list 00672911 or 00745310

Also listed as
5EPJ1163 5PJE1163 1163J5EL 52X5974 00672911 00745310

Note: Always verify the original belt is marked 5EPJ1163, 5PJE1163 or 52X5974. This is the 5-rib / 1163 mm elastic belt. New belt looks shorter than the old stretched one — stretch it on during install. One washer requires 1 belt. Compatibility may vary by production year.

Applications

• Washer drum does not turn
• Belt snapped or stretched
• Slipping or burning rubber smell
• Ideal for home DIY and technicians

Package Includes

• 1 × Washer Drive Belt (5EPJ1163 / 52X5974 Compatible)
