1Pc Switch Meter Flowmeter Counter 0.3-6L/min Water Coffee Flow Sensor Connected To 6mm Hose DIY Accessories
1Pc Switch Meter Flowmeter Counter 0.3-6L/min Water Coffee Flow Sensor Connected To 6mm Hose DIY Accessories
CHECK BEFORE YOU CHOOSE
Match the machine model and component reference. Check dimensions, thread or portafilter size and the selected quantity where applicable.
Part details & fitting checklist ↓Couldn't load pickup availability
Product description & listing images
Description
External threads: 1/4"
temperature: -25~+80 Celsius
Allowing pressure: pressure 1.75Mpa
Operating humidity range: 35%~90%RH (no frost)
Use temperature: ≤ 80 Celsius
Load capacity: ≤ 10 mA (DC 5V)
Working voltage range: DC 5~18 v
Maximum operating current: 15 mA (DC 5V)
The lowest rated working voltage: DC4.5 5V-24V
Size : 5.7cmX4cm/2.24''X1.57''
Color : white
Material: Metal+Plastic
Lead Way:
Red IN connect the anode
Yellow OUT signal output line
Black GND connect the cathode
Package includes:
1* Coffee Maker Water Dispenser Flowmeter Flow Sensor
Note:
1. The color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. Please refer to the actual product received.
2. Please allow slight manual measurement deviation for the data.
KNOW WHAT YOU ARE CHOOSING
Part details & buying guide
Product details
- Part type
- Coffee Machine Spare Parts
- Part listing
- 1Pc Switch Meter Flowmeter Counter 0.3-6L/min Water Coffee Flow Sensor Connected To 6mm Hose DIY Accessories
- color
- 1pc
- Checkout currency
- USD
The listing images and selected option describe the item offered. If the pack quantity or included components are unclear, ask us before ordering.
Check the fit before ordering
- Use the complete device model, including its suffix.
- Match the machine model and component reference. Check dimensions, thread or portafilter size and the selected quantity where applicable.
- A search match or shared brand name does not confirm compatibility. Ask us if the exact model is not stated.
